Legacy Toolchains Are Fragmented
Modern engineering teams lose thousands of hours converting STEP files, re-meshing geometry for cloud FEA solvers, and manually post-processing 5-axis CNC G-Code.
Disjointed CAD & FEA
Exporting STEP files to external solvers causes topological naming corruption, breaking sketch dependencies.
Unconstrained Cloud AI
Generic text LLMs hallucinate non-physical geometry with zero understanding of material yield limits or von Mises stress.
Cloud Data Leakage
SaaS CAD tools expose sensitive defense and aerospace intellectual property over public cloud endpoints.
ZylForge Core Modules
Six interconnected modules executing inside an air-gapped desktop workspace.
1. Parametric B-Rep Modeler
True NURBS curves, analytical surfaces, and G2 curvature edge fillets.
View Modeler Docs →2. Local Neural AI Assistant
Physics-constrained ONNX inference running 100% on workstation GPU.
View AI API Docs →3. FEA Validation Engine
Tet10 meshing, von Mises yield stress, and 2.5x aerospace safety factor.
View FEA Specs →4. Automated Drawing Builder
ISO/ANSI 2D drafting sheets, ASME Y14.5 GD&T callouts, and live BOM.
View Drawing Engine →5. 5-Axis CNC Manufacturing
5-axis simultaneous G-Code post-processor & collision detection.
View CNC Specs →6. Sovereign Data Vault
Encrypted SQLite data payloads (.zforge) with zero cloud lock-in.
View ADR-0002 Spec →Eagle Rock Static Test Stand
Our open-source aerothermal propulsion suite. Includes liquid oxygen injector plate schematics, 50 bar pressure CFD solvers, and public Python telemetry models.
Africa-Led. Global Grade.
Zylvex proves that world-class physical AI engineering software and aerothermal propulsion algorithms can originate anywhere on earth. Our AERI initiative equips university laboratories with open hardware compute nodes.
40% Cycle Time Reduction
Eliminating STEP translation errors between design and CNC toolpaths.
Zero Cloud IP Exposure
Air-gapped desktop execution under ADR-0002 protects defense assets.
